| Max workpiece cross-section size | 8 inch/10inch | Max cutting fluid tank capacity | 150L |
| Max workpiece length | 300mm | TTV | Average Value ≤15μm |
| Main wire diameter | ≥Φ0.10mm | WARP | Average Value ≤30μm |
|
Max wire speed |
30m/s | BOW | Average Value ≤20μm |
| Max storage capacity of Take-up wheel | 300~800km | Main spindle lubrication method | Grease lubrication |
| Fixture swing angle | 0±12° | Equipment overall power | 120kW |
| Wire tension | 0~50N | Equipment weight | 13.5t |
| Number of main cutting rollers | 3 | Equipment size | 4300*h2200*3400mm |
1.Stable Structure: The integrated cast structure ensures a stable and durable machine base, providing consistent performance.
2.High Precision: A self-developed spindle box structure exceeds industry accuracy standards.
3.Reliable Performance: Equipped with Siemens motion control and motors, ensuring long-term stability and smooth operation.
4.Even Cutting Force: The swing fixture mechanism ensures uniform cutting forces during processing.
5.Efficient Cooling: Independent water tank cooling system prevents condensation in the spindle box, maintaining performance.
6.Excellent indicator control: Advanced control of TTV, WARP, BOW, and other indicators ensures high-quality processing.
7.Accurate Crystal Orientation: Patented T-slot positioning system ensures precise crystal orientation processing.
8.Precise Tension Control: The self-developed software system guarantees accurate tension control for optimal results.
